Model

MPE-7501-AFAAG

ATX Version

ATX 12V Ver. 2.41

PFC

Active PFC

Input Voltage

100-240V

Input Current

10-5A

Input Frequency

47-63Hz

Dimensions (L x W x H)

160 x 150 x 86 mm

Fan Size

120mm

Fan Bearing

HDB

Fan Speed

1500 RPM

Noise Level @ 20%

0 dBA

Noise Level @ 50%

17.8 dBA

Noise Level @ 100%

24.9 dBA

Efficiency

≥90% @ Typical Load

80 PLUS Rating

80 PLUS Gold

ErP 2014 Lot 3

Yes

Operating Temperature

0-50°C

Power Good Signal

100 - 150 ms

Hold Up Time

>16ms at 100% Load

MTBF

>100,000 Hours

Protections

OVP, OPP, OTP, SCP, OCP, UVP

Regulatory

TUV, CE, CCC, EAC, RCM, cTUVus, FCC, BSMI, BIS, UKCA

ATX 24 Pin Connectors

1

EPS 4 4 Pin Connectors

1

EPS 8 Pin Connector

1

SATA Connectors

12

Peripheral 4 Pin Connectors

4

PCI-e 6 2 Pin Connectors

4

Series

MWE Gold Series

80 Plus

Gold

Modular

Full Modular

Wattage

500 to 750W
