Specifications:

• Product Number: MPW-6001-ACBW-BEU

• Model: MPW-6001-ACBW-B
• ATX Version: ATX 12V Ver. 2.41
• PFC Active: PFC
• Input Voltage: 200-240V
• Input Current: 4.5A
• Input Frequency: 50-60Hz
• Dimensions (L x W x H): 140 x 150 x 86 mm
• Fan Size: 120mm
• Fan Bearing: Sleeve Fan
• Efficiency: ≥ 85% @ Typical Load
• ErP 2014 Lot 3: Yes
• Operating Temperature: 0-40°C
• Power Good Signal: 100 - 500 ms
• Hold Up Time: ≥10ms at 100% load
• MTBF: >100,000 Hours
• Protections: OVP, OPP, SCP, UVP, OTP, Inrush Protection
• Regulatory: TUV, cTUVus, CE, FCC, CCC, EAC, UKCA

Connectors

• ATX 24 Pin Connectors: 1
• EPS 4 4 Pin Connectors: 1
• SATA Connectors: 5
• Peripheral 4 Pin Connectors: 3
• PCI-e 6 2 Pin Connectors: 2

• Series Elite Series: 80 Plus Standard
• Modular Non Modular: Wattage 500 to 750W
