• Product Number: EY7A007
• Total power: 650 W
• AC input voltage: 115 - 240 V
• AC input frequency: 50 - 60 Hz
• Power Factor Correction (PFC) type: Active
• Max output current ( 3.3V): 20 A
• Max output current ( 12V): 54 A
• Max output current ( 5V): 20 A
• Max output current (-12V): 0.3 A
• Max output current ( 5Vsb): 3 A
• Power protection features
• OCP (overcurrent protection)
• OPP (overload protection)
• OTP (overheat protection)
• Expand

Ports & interfaces

• Motherboard power connector: 20 4 pin ATX
• Motherboard power cable length: 60 cm
• Number of SATA power connectors: 5
• SATA power cable length:
• 560 mm
• 880 mm
• Peripheral (Molex) power connectors (4-pin): 1
• Peripheral (Molex) power cable length: 880 mm
• PCI Express power connectors (6 2 pin): 2
• PCI Express power cable length: 56 cm
• EPS power connector (4 4 pin): 2
• Length of EPS power connectors (4 4 pin): 705 mm
• Modular cabling: Yes

Performance

• 80 PLUS certification: 80 PLUS Gold
• Power supply unit (PSU) form factor: ATX
• ATX version: 2.31

Design

• Product colour: Black
• Cooling type: Active
• Fan diameter: 12 cm
• Number of fans: 1 fan(s)
• Fan location: Top
• On/off switch: Yes

Weight & dimensions

• Width: 150 mm
• Depth: 140 mm
• Height: 87 mm
• Weight: 1.44 kg
