Specifications

	XR15 G5 PRO	XR30 G5 PRO	XR15 G5 Blue	XR30 G5 Blue
Length	7in.(18cm)	11.8in.(30cm)	7in.(18cm)	11.8in.(30cm)
Width	7in.(18cm)	7in.(18cm)	7in.(18cm)	7in.(18cm)
Height	1.5in.(3.9cm)	1.5in.(3.9cm)	1.5in.(3.9cm)	1.5in.(3.9cm)
Power Consumption	105W	215W	100W	205W
Universal Input Range	100-240VAC, 2.5A;	100-240VAC, 2.5A;	100-240VAC, 2.5A;	100-240VAC, 2.5A;
LEDs	12 - Cool White	24 - Cool White	3 - Cool White	6 - Cool White
	16 - Royal Blue	32 - Royal Blue	20 - Royal Blue	40 - Royal Blue
	8 - Blue	16 - Blue	12 - Blue	24 - Blue
	2 - Photo Red	4 - Photo Red	1 - Photo Red	2 - Photo Red
	3 - Green	6 - Green	2 - Lime	4 - Lime
	4 - UV	4 - UV 415 / 4 - UV 405	2 - UV 405 / 2 - UV 415	4 - UV 405 / 4 - UV 415
	2 - Violet	4 - Violet	3 - Violet	6 - Violet
	3 - Warm White	6 - Warm White	5 - Cyan	10 - Cyan
	2 - Lunar Light	2 - Lunar Light	2 - Lunar Light	2 - Lunar Light

Mounting

SINGLE ARM RMS

These two specialized kits are designed for XR15 and XR30 model Radions. Each kit contains everything needed to mount a Radion light on almost any standard or rimless tank.

Each kit contains multiple sliding rails and a rotatable x-bracket, allowing you to easily position your Radion precisely where you need it.

MULTI-LIGHT RMS

The Multi-Light RMS offers a customizable multi-light mount solution for Radion XR30 and Radion XR15 lights. The Multi-Light RMS system features:

• Built-in cable management
• Compatibility with rimmed, rimless and euro-braced tanks
• Rigid yet lightweight construction
• Anodized aluminum finish
• Slide mounts for horizontal and rotational adjustment
• Optimal mounting for Radions at approximately 7 inches (18 cm) above the edge of the tank
