General Specifications:

• Product Line: AMD Ryzen™ 7 Desktop Processors
• # of CPU Cores: 8
• # of Threads: 16
• Max. Boost Clock: Up to 5.4GHz
• Base Clock: 4.5GHz
• L1 Cache: 512KB
• L2 Cache: 8MB
• L3 Cache: 32MB
• Default TDP: 105W
• Unlocked for Overclocking: Yes
• CPU Socket: AM5
• Thermal Solution (PIB): Not included
• Max. Operating Temperature (Tjmax): 95°C
• Launch Date: 9/27/2022

Connectivity

• Memory Channels: 2
• Max Memory Speed
• 1x1R: 5200 MT/s
• 1x2R: 5200 MT/s
• 2x1R: 3600 MT/s
• 2x2R: 3600 MT/s

Graphics Capabilities

• Graphics Model: AMD Radeon™ Graphics
• Graphics Core Count: 2
• Graphics Frequency: 2200 MHz
• GPU Base: 400 MHz

Key Features

• Supported Technologies: AMD EXPO™ Technology, AMD Ryzen™ Technologies
