ATX Version

ATX 12V V2.52

PFC

Active PFC

Input Voltage

100-240V

Input Current

10-5A

Input Frequency

50-60Hz

Dimensions (L x W x H)

140 x 150 x 86 mm

Fan Size

120mm

Fan Bearing

HDB

Fan Speed

2400 RPM

Noise Level @ 20%

11.06 dBA

Noise Level @ 50%

22.3 dBA

Noise Level @ 100%

41.3 dBA

Efficiency

85% Typically

80 PLUS Rating

80 PLUS Bronze

ErP 2014 Lot 3

Yes

Operating Temperature

40°C

Power Good Signal

100 - 500 ms

Hold Up Time

>18ms at 100% Full Load@230Vac

MTBF

>100,000 Hours

Protections

OVP, OPP, SCP, UVP, OTP

Regulatory

CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB

ATX 24 Pin Connectors

1

EPS 4 4 Pin Connectors

1

EPS 8 Pin Connector

1

SATA Connectors

8

Peripheral 4 Pin Connectors

4

PCI-e 6 2 Pin Connectors

4

80 Plus

Bronze

Modular

Non Modular

Wattage

500 to 750W

Series

MWE Bronze Series
